Specifications
CPU Specifications
Total Cores: 8
Total Threads: 16
Max Turbo Frequency: 4.80 GHz
Intel® Turbo Boost Max Technology 3.0 Frequency: 4.80 GHz
Intel® Turbo Boost Technology 2.0 Frequency: 4.70 GHz
Processor Base Frequency: 2.90 GHz
Cache: 16 MB Intel® Smart Cache
Bus Speed: 8 GT/s
TDP: 65 W
Supplemental Information
Embedded Options Available: No

Datasheet View now

Memory Specifications
Max Memory Size (dependent on memory type): 128 GB
Memory Types: DDR4-2933
Max no of Memory Channels: 2
Max Memory Bandwidth: 45.8 GB/s
ECC Memory Supported: No
Processor Graphics
Processor Graphics: Intel® UHD Graphics 630
Graphics Base Frequency: 350 MHz
Graphics Max Dynamic Frequency: 1.20 GHz
Graphics Video Max Memory: 64 GB
4K Support: Yes, at 60Hz
Max Resolution (HDMI): 4096 x 2160@30Hz
Max Resolution (DP): 4096 x 2304@60Hz
Max Resolution (eDP – Integrated Flat Panel): 4096 x 2304@60Hz
DirectX* Support: 12
OpenGL* Support: 4.5
Intel® Quick Sync Video: Yes
Intel® InTru™ 3D Technology: Yes
Intel® Clear Video HD Technology: Yes
Intel® Clear Video Technology: Yes
No of Displays Supported: 3
Device ID: 0x9BC5
Expansion Options
Scalability: 1S Only
PCI Express Revision: 3.0
PCI Express Configurations: Up to 1×16, 2×8, 1×8+2×4
Max # of PCI Express Lanes: 16
Package Specifications
Sockets Supported: FCLGA1200
Max CPU Configuration: 1
Thermal Solution Specification: PCG 2015C
TJUNCTION: 100°C
Package Size: 37.5mm x 37.5mm
Advanced Technologies
Intel® Optane™ Memory Supported: Yes
Intel® Thermal Velocity Boost: No
Intel® Turbo Boost Max Technology 3.0: Yes
Intel® Turbo Boost Technology: 2.0
Intel vPro® Platform Eligibility: Yes
Intel® Hyper-Threading Technology: Yes
Intel® Virtualization Technology (VT-x): Yes
Intel® Virtualization Technology for Directed I/O (VT-d): Yes
Intel® VT-x with Extended Page Tables (EPT): Yes
Intel® Transactional Synchronization Extensions: No
Intel® 64: Yes
Instruction Set: 64-bit
Instruction Set Extensions: Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
Idle States: Yes
Enhanced Intel SpeedStep® Technology: Yes
Thermal Monitoring Technologies: Yes
Intel® Identity Protection Technology: Yes
Intel® Stable Image Platform Program (SIPP): Yes
Security & Reliability
Intel® AES New Instructions: Yes
Secure Key: Yes
Intel® Software Guard Extensions (Intel® SGX): Yes, with Intel® ME
Intel® OS Guard: Yes
Intel® Trusted Execution Technology: Yes
Execute Disable Bit: Yes
Intel® Boot Guard: Yes
