"Specifications

General

Platform: Boxed Processor

Product Family: AMD Ryzen™ Processors

Product Line: AMD Ryzen™ 9 Desktop Processors

Former Codename: “Matisse”

# Of CPU Cores: 12

# Of Threads: 24

Boost Clock: Up to 4.6GHz

Base Clock: 8GHz

L1 Cache: 768KB

L2 Cache: 6MB

L3 Cache: 64MB

Default TDP: 105W

Processor Technology for CPU Cores: TSMC 7nm FinFET

Unlocked for Overclocking: Yes

CPU Socket: AM4

Thermal Solution (PIB: Wraith Prism with RGB LED

Thermal Solution (MPK): Wraith PRISM

Operating Temperature (Tjmax): 95°C

Launch Date: 7/7/2019

*OS Support: Windows 10 – 64-Bit Edition; RHEL x86 64-Bit; Ubuntu x86 64-Bit

*Operating System (OS) support will vary by manufacturer.

Connectivity

PCI Express® Version: PCIe 4.0 x16

System Memory Type: DDR4

Memory Channels: 2

System Memory Specification: Up to 3200MHz

Graphics Capabilities

Integrated Graphics: No

Graphics Model: Discrete Graphics Card Required

Product IDs

Product ID Boxed: 100-100000023BOX

Product ID Tray: 100-000000023

Product ID MPK: 100-100000023MPK"
