"Specifications

Camera

Image Sensor 1/3” 4Megapixel progressive CMOS

Max. Resolution 2688 (H) × 1520 (V)

ROM 128 MB

RAM 128 MB

Scanning System Progressive

Electronic Shutter Speed Auto/Manual 1/3 s–1/100000 s

S/N Ratio > 56 dB

Min. Illumination 0.008 Lux@F1.6

Illumination Distance 30 m (98.43 ft)

Illuminator On/Off Control Auto/Manual

Illuminator Number 1 (IR LED)

Pan/Tilt/Rotation Range Pan: 0°–360°

Tilt: 0°–90°

Rotation: 0°–360°

Lens

Lens Type Fixed-focal

Mount Type M12

Focal Length 2.8 mm

3.6 mm

Max. Aperture F1.6

F1.6

Field of View 2.8 mm:

Horizontal:102.0° × Vertical 55.0° × Diagonal 121.0°3.6 mm :

Horizontal 84.0° × Vertical 45.0° × Diagonal 100.0°

Iris Type Fixed

Close Focus Distance 2.8 mm: 0.9 m (2.95 ft)

3.6 mm: 1.6 m (3.61 ft)

DORI Distance Lens Detect Observe Recognize Identify

2.8 mm 56 m (183.73 ft) 22.4 m

(73.49 ft)

11.2 m

(36.75 ft)

5.6 m

(18.37 ft)

3.6 mm 80 m (262.47 ft) 32.0 m (104.99 ft) 16.0 m

(52.49 ft)

8.0 m

(26.25 ft)

Smart event

IVS Tripwire; intrusion

Video

Video Compression H.265; H.264; H.264B; MJPEG(only supported

by sub stream)

Smart Codec Smart H.265+/ Smart H.264+

Video Frame Rate Main stream:

2688 × 1520 (1 fps-20 fps)

2560 × 1440 (1 fps-25/30 fps)

Sub stream:

704 × 576 (1 fps-25 fps)

704 × 480 (1 fps-30 fps)

Stream Capability 2 streams

Resolution 2688 × 1520 (2688 × 1520); 2560 × 1440 (2560 × 1440); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 ×480); CIF (352 × 288/352 × 240)

Bit Rate Control CBR/VBR

Video Bit Rate H.264: 32 kbps–6144 kbps

H.265: 12 kbps–6144 kbps

Day/Night Auto(ICR)/Color/B/W

BLC Yes

HLC Yes

WDR 120 dB

White Balance Auto/natural/street lamp/outdoor/manual/regional custom

Gain Control Auto/Manual

Noise Reduction 3D NR

Motion Detection OFF/ON (4 areas, rectangular)

Region of Interest(RoI) Yes (4 areas)

Smart Illumination Yes

Image Rotation 0°/90°/180°/270° (Supports 90°/270° with 2688 × 1520 resolution and lower.)

Mirror Yes

Privacy Masking 4 areas

Alarm

Alarm Event No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; voltage detection; security exception

Network

Network RJ-45 (10/100 Base-T)

SDK and API Yes

Cyber Security Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade

Protocol IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; 802.1x; Bonjour

Interoperability ONVIF(Profile S/Profile G/Profile T);CGI; P2P; Milestone; Genetec

User/Host 20

Storage FTP; SFTP; Micro SD Card (support max. 256 GB); NAS

Browser IE

Chrome

Firefox

Management Software Smart PSS; DSS; DMSS

Mobile Phone IOS; Android

Certification

Certifications CE-LVD: EN62368-1

CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU

FCC: 47 CFR FCC Part 15, Subpart B

UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07

Power

Power Supply 12V DC/PoE (802.3af)

Power Consumption < 5W

Environment

Operating Conditions -40°C to +60°C (-40°F to +140°F)/less than ≤ 95% RH

Strorage Conditions -40°C to +60°C (-40°F to +140°F)

Protection IP67

Structure

Casing Metal

Dimensions 166.2 mm × Φ70 mm (6.54″ × Φ2.76″)

Net Weight 0.48 kg (1.1 lb)

Gross Weight 0.57 kg (1.3 lb)"
