Specifications

Camera

Image Sensor 1/2.8” 2Megapixel progresive CMOS

Effective Pixels 1920(H) x1080(V)

RAM/ROM 64MB/16MB

Scanning System Progressive

Electronic Shutter Speed Auto/Manual, 1/3~1/100000s

Minimum Illumination 0.01 lux@F2.0 (Color, 30 IRE)

0.001 lux@F2.0 (B/W, 30 IRE)

0 lux (Illuminator on)

S/N Ratio More than 56dB

IR Distance Distance up to 30m(98ft)

IR On/Off Control Auto/ Manual

IR LEDs 1

Lens

Lens Type Fixed

Mount Type M12

Focal Length 2.8 mm

3.6 mm

Max. Aperture F2.0/

F2.0

Angle of View 2.8 mm: Horizontal: H: 102°; V: 54°; D: 120°

3.6 mm: Horizontal: H: 88°; V: 47°; D: 104

Focus Control Fixed

Close Focus Distance 2.8 mm: 0.5 m (1.6 ft)

3.6 mm: 0.8 m (2.62 ft)

DORI Distance Lens Detect Observe Recognize Identify

2.8 mm 38.6 m (126.64 ft) 15.4 m (50.52 ft) 7.7 m (25.26 ft) 3.9 m (12.80 ft)

3.6 mm 49.7 m (163.06 ft) 19.9 m (65.29 ft) 9.9 m (32.48 ft) 5.0 m (16.40 ft)

PTZ

Pan/Tilt Range Pan:0° ~360° ;Tilt:0° ~90° ;Rotation:0° ~360°

Intelligence

Event Trigger Motion detection, Video tampering, Scene changing, Network disconnection, IP address conflict, Illegal access, Storage anomaly

IVS NA

Video

Compression H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)

Smart Codec Smart H.265+; Smart H.264+

Streaming Capability 2 Streams

Resolution 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)

Frame Rate Main stream: 1920 × 1080@1–25/30 fps

Sub stream: 704 × 576@1–25 fps 704 × 480@1–30 fps

*The values above are the max. Frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.

Bit Rate Control CBR/VBR

Bit Rate H.264: 32 kbps–6144 kbps

H.265: 12 kbps–6144 kbps

Day/Night Auto(ICR) / Color / B/W

BLC Mode BLC / HLC / DWDR

White Balance Auto/Natural/Street Lamp/Outdoor/Manual

Gain Control Auto/Manual

Noise Reduction 3D DNR

Motion Detection Off / On (4 Zone, Rectangle)

Region of Interest Off / On (4 Zone)

Electronic Image Support

Smart IR Support

Digital Zoom 16x

Flip 0°/90°/180°/270°

Mirror Off / On

Privacy Masking Off / On (4 Area, Rectangle)

Audio

Compression

Built-in MIC

G.711A; G.711Mu; G.726

Yes

Network

Ethernet RJ-45 (10/100Base-T)

Protocol HTTP;HTTPs;TCP;ARP;RTSP;RTP;RTCP;UDP;SMTP;

FTP;DHCP;DNS;DDNS;PPPoE;IPv4/v6;QoS;UPnP;

NTP;Bonjour;IEEE 802.1x;Multicast;ICMP;IGMP;

TLS

Interoperability ONVIF Profile S&G, API

Streaming Method Unicast / Multicast

Max. User Access 10 Users / 20 Users

Edge Storage NAS

Local PC for instant recording

Web Viewer IE, Chrome, Firefox, Safari

Management Software Smart PSS, DSS, DMSS

Smart Phone IOS, Android

Certifications

Certifications CE (EN 60950:2000)

UL:UL60950-1

FCC: FCC Part 15 Subpart B

Interface

Video Interface N/A

Audio Interface N/A

RS485 N/A

Alarm N/A

Electrical

Power Supply DC12V, PoE (802.3af)(Class 0)

Power Consumption Basic: 1.2 W (12 VDC); 2 W (PoE) Max. (ICR + H.265 + IR intensity): 3.2 W (12 VDC); 4.1 W (PoE

Environmental

Operating Conditions -40° C ~ +60° C (-40° F ~ +140° F) / Less than 95% RH

Strorage Conditions -40° C ~ +60° C (-40° F ~ +140° F) / Less than 95% RH

Ingress Protection IP67

Vandal Resistance N/A

Construction

Casing Metal+Plastic

Dimensions 162.6 mm × 70 mm× 70 mm (6.4″ × 2.8″ × 2.8″) (L × W × H)

Net Weight 0.22 kg (0.5 lb)

Gross Weight 0.34 kg (0.7 lb)
