"Specification

Imaging

Image Sensor: 1-Chip 1″ MOS Sensor

Sensor Resolution: 3840 x 2160 (8.59 MP)

Effective Sensor Resolution: 3840 x 2160 (8.59 MP)

Gain: 0 to 30 dB (Native)

Minimum Illumination: 1.3 Lux at 1/30 Shutter Speed

White Balance Range: 2000 to 15,000K

Lens

Focal Length: 8.8 to 132mm

35mm Equivalent Focal Length: 24.5 to 367.5mm

Optical Zoom Ratio: 15x

Max Digital Zoom: 10x

Maximum Aperture: f/2.8

Minimum Aperture: f/4.5

Minimum Focusing Distance: Not Specified by Manufacturer

Filter Size: 67 mm

Control Rings: Focus, Zoom, Iris

Image Stabilization: Optical

Focus Control: Autofocus, Manual Focus

Camera

Shutter Speed: 1/60 to 1/8000 sec

Scan Rate Adjustable: Yes

Built-In ND Filter: None

Built-In Microphone Type: Stereo

Media/Memory Card Slot: Dual Slot: SD/SDHC/SDXC (UHS-I) [Class 10/U1/V10 or Faster Recommended]

Recording

Recording Modes: MP4 4:2:0 8-Bit:

3840 x 2160p at 23.98/29.97 fps (100 Mb/s)

1920 x 1080p at 23.98/29.97/59.94 fps (50 to 200 Mb/s)

AVCHD 4:2:0 8-Bit:

1920 x 1080p at 23.98/59.94 fps (21 to 25 Mb/s)

1920 x 1080i at 59.94 fps (17 to 21 Mb/s)

1440 x 1080i at 59.94 fps (5 Mb/s)

1280 x 720p at 59.94 fps (8 Mb/s)

720 x 480i at 59.94 fps (9 Mb/s)

Variable Frame Rates: 1080p: 2 to 60 fps

1080p: 2 to 60 fps

Audio Recording: MP4: 2-Channel 16-Bit 48 kHz LPCM Audio

AVCHD: 2-Channel 16-Bit 48 kHz LPCM Audio

Still Image Support: JPEG

3 MP (3840 x 2160)

1 MP (1920 x 1080)

9 MP (1280 x 720)

IP Streaming: None

Interfaces

Video Connectors: 1 x RCA (Composite) Output

1 x HDMI Output

Audio Connectors: 2 x 3-Pin XLR Mic/Line Level (+48 V Phantom Power) Input

1 x 1/8″ / 3.5 mm Stereo Headphone Output

Other I/O: 1 x 2.5 mm Camera Interface Control Input

1 x 3.5 mm Camera Interface Control Input

1 x USB Type-A Camera Interface Data Output

1 x USB Micro-B Camera Interface Data Input/output

Display

Display Type: Articulating LCD

Size: 3.5″

Resolution: 1,150,000 Dot

EVF

EVF Display Type: OLED

Screen Size: 0.24″

EVF Resolution: 1,560,000 Dots

Power

Battery Type: Panasonic AG-VBR Series

Power Connectors: 1 x Proprietary (7.2 to 12 VDC) Input

Power Consumption: 12.2 W

Environmental

Operating Temperature: 32 to 104°F / 0 to 40°C

Operating Humidity: 10 to 80%

General

Accessory Mount: 1 x Cold Shoe Mount

Tripod Mount: 1/4″-20 Female

Dimensions: 6.65 x 7.68 x 13.39″ / 169 x 195 x 340 mm (Without Protrusions)

Weight: 4.2 lb / 1.91 kg

Warranty Length: Limited 1-Year Warranty

Packaging Info

Package Weight: 9.8 lb

Box Dimensions (L x W x H): 18.4 x 13.1 x 11.1″"
