"XLR Input for Pro-Quality Audio

In addition to the internal high-performance stereo microphone, the AG- AC160 comes equipped with two-channel XLR audio input terminals with a 48V phantom power supply. The internal microphone, external microphone, or line input can be selected for each channel. Large, easy-to-use level dials are also provided.

Zebra

Select any two zebra levels from 50 to 105% (in 5% steps).

USB 2.0

The type mini-USB Type-B port allows for connection to a PC in device mode.

Remote Terminal

Enables remote operation of iris, focus, Rec start/stop, and index functions.

Color Bar

Outputs a color bar signal and test tone.

Tally Lamps

Tally lamps are provided on the front and rear.

Specification

Imaging

Image Sensor: 1-Chip 1″ MOS Sensor

Sensor Resolution: Actual: 4096 Megapixel2160

Effective: 9.46 Megapixel

Gain: 0 to 24 dB (Native)

-3 to 24 dB (Expanded)

Sensitivity: f/11 at 2000 lux 89.9% Reflectance

Minimum Illumination: 0.2 Lux at 1/2 Shutter Speed

White Balance Range: 2000 to 15,000K

Lens

Focal Length: 8.8 to 176mm

35mm Equivalent Focal Length: 25.4 to 508mm

Optical Zoom Ratio: 20x

Max Digital Zoom: 10x

Maximum Aperture: f/2.8 to 4.5

Minimum Aperture: f/22

Minimum Focusing Distance: Not Specified by Manufacturer

Filter Size: 67 mm

Control Rings: Focus, Zoom, Iris

Image Stabilization: Optical, Digital

Focus Control: None

Camera

Shutter Speed: 1/60 to 1/8000 sec

Scan Rate Adjustable: Yes

Built-In ND Filter: Mechanical Filter Wheel with Clear, 2 Stop (1/4), 4 Stop (1/16), 6 Stop (1/64) ND Filters

Built-In Microphone Type: Stereo

Media/Memory Card Slot: Dual Slot: SD/SDHC/SDXC (UHS-I)

Recording

Recording Modes: MP4:

4096 x 2160p (100 Mb/s)

3840 x 2160p (100 to 200 Mb/s)

1920 x 1080p (50 to 200 Mb/s)

Variable Frame Rates: 1080p: to 120 fps

1080p: to 100 fps

1080p: 2 to 60 fps

1080p: 2 to 50 fps

Audio Recording: MP4: 2-Channel 16-Bit 48 kHz LPCM Audio

AVCHD: 2-Channel 16-Bit 48 kHz LPCM Audio

Still Image Support: JPEG

8.8 MP (4096 x 2160)

8.3 MP (3840 x 2160)

2.1 MP (1920 x 1080)

0.9 MP (1280 x 720)

IP Streaming: None

Interfaces

Video Connectors: 1 x BNC (3G-SDI) Output

1 x 1/8″ (3.5 mm) TRRS A/V (Composite) Output

1 x HDMI (HDMI 2.0) Output

Audio Connectors: 2 x 3-Pin XLR Mic/Line Level (+48 V Phantom Power) Input

1 x 1/8″ / 3.5 mm Stereo Mic/Line Level Output

1 x 1/8″ / 3.5 mm Stereo Headphone Output

Other I/O: 1 x 2.5 mm Camera Interface Control Input

1 x 3.5 mm Camera Interface Control Input

1 x BNC Timecode Input/Output

1 x USB Type-A Camera Interface Data Output

1 x USB Micro-B Camera Interface Data Output

Display

Display Type: Articulating LCD

Size: 3.5″

Resolution: 1,150,000 Dot

EVF

EVF Display Type: OLED

Screen Size: 0.39″

EVF Resolution: 1,770,000 Dots

Power

Battery Type: Panasonic AG-VBR Series

Power Connectors: 1 x Proprietary (7.2 to 12 VDC) Input

Power Consumption: 19.7 W

Environmental

Operating Temperature: 32 to 104°F / 0 to 40°C

Operating Humidity: 10 to 80%

General

Accessory Mount: 1 x Cold Shoe Mount

Tripod Mount: 1/4″-20 Female

Dimensions: 6.8 x 7.68 x 13.62″ / 172.7 x 195.07 x 345.95 mm

Weight: 4.4 lb / 2 kg

Warranty Length: Limited 1-Year Warranty

Packaging Info

Package Weight : 10 lb

Box Dimensions (L x W x H): 18.3 x 13.2 x 11.2″"
