Product features
1 High precision infrared sensor.
2 Strong environmental temperature adaptability. 3.3 Automatically save the last measured value.
3 Large LCD screen, high brightness backlight.
4. Two temperature units, Celsius and Fahrenheit, are optional.
5. Automatic power-off and energy saving.
6. Clean and sanitary: non-contact forehead temperature measurement, measuring distance 3cm, no contact with human skin, to prevent cross infection.
7. One key measurement, one key memory value check.
8. Multi group memory: it can store 50 groups of measurement data for analysis and comparison.
PRODUCUT PERFORMANCE
Accurate
Measurement Deviation < +- 0.3°C Fast 1 second measurement Safety Non-Contact temperature measurement Service life 3 years Store data 10 sets of stored data Storagae conditions Ventilation and drying:- 20°C- 55°C Unit Conversion °C / °Fcan be converted to each other Repeated measutement consistency Consistency <0.2°C Intented use To display the temperature of the measured object by measuring the heat of the forehead with an accurate sensing optical system (the risk of cross infection can be avoided without touching the human skin). it is especially suitable for occasions requiring rapid and accurate temperature measurement such as hospitals families, schools kindergartens and stations. TECHINCAL INDEX Normal operating conditions Ambient temperature 10°C – 40°C Relative humidty < 85%RH Power supply voltage 3V(2AA Size battery) Measurement range 32.0°C-42.9°C Resolution 0.1°C Accuracy Within 32°C-34.9°C +-0.3°C Within 35°C-40.0°C +-0.2°C Within 42.1°C-42.9°C +-0.3°C Measuring distance 1-5cm Automatic shutdown 30 seconds Enclosure Instruction 1 Certificate 1 Modify Settings In the state of power-on, press and hold the set key for about 3 seconds to enter the thermometer setting interface. Then press (SET)to switch; switching sequence_F1 F2 F3 F4 to save and shut down. 1. F1 interface — temperature display unit switch, press the memo and mode keys to switch. 2. F2 interface –adjust the warning temperature, and press the memo and mode to modify the temperature value. If the temperature is higher than the value, the red backlight will warn. 3. F3 interface — horn on and off function settings, press memo or mode to modify. 4. F4 interface — temperature overall offset setting, press memo and mode to modify the temperature offset value. 5. Press the (SET) set key again to shut down and save the modified value. 8.Body Temperature Measurement This product provides you with the temperature measurement method of forehead temperature, but it can’t replaced the doctor’s diagnosis and treatment. In addition, the individual’s temperature is not the same. Please use the memory function to know your daily temperature, and take this as a reference for whether the temperature rises.
