Basic Information

Brand : Walton

model : WSN-RIVERINE-24BH

Series name : Riverine

Air conditioner type : Non-Inverter

function

Heating & Cooling

Cooling capacity (ton) : 2 Ton compressor

Rotary (Fixed Speed) :

Refrigerant : R-410a

Technology : Non-Inverter

Cooling capacity (btu/hr) : 24000 BTU/Hr

cooling capacity (w)

Cooling: 6700W,

 Heating: 6700W

Rated voltage : 230V~50Hz

rated power

Cooling: 2361W,

Heating: 2095W

rated current (a)

Cooling: 10.85,

Heating: 9.82

eer

Cooling: 2.83

cop

Heating: 3.19

Detailed Information

Refrigerant amount (kg) :1.57

operating range (ambient temperature)

Cooling: 20˚C to 46˚C, Heating: –7˚C to 24˚C

indoor fin type : Louvered Fin

indoor heat exchanger tube type : Copper Tube

outdoor heat exchanger tube type : Slit Fin

maximum pipe length :15m

turbo mode : Yes

dry mode

Yes (Cooling Mode Only) :

auto operation : Yes

auto restart : Yes

fan mode : Yes

speed setting : Yes (Auto, High, Medium, Low)

comfort cooling : Yes

timer : Yes

sleep : Yes

display type : LCD

operation/control

Via IR (Infrared Ray) child lock : Yes

temperature unit change :Yes

auto up-down swing : Yes

auto left-right swing :Yes

indoor dimensions (mm) [l×w×h]

Unit : 1097 x 329.21 x 239.12,

Packing: 1180 x 410 x 315

outdoor dimensions (mm) [l×w×h]:

Unit: 865 x 370 x 687, Packing: 935 x 435 x 750

net weight (indoor) (kg) : 16 ± 0.5

gross weight (indoor) (kg) : 19 ± 0.5

net weight (outdoor) (kg) : 48 ± 1

gross weight (outdoor) (kg) : 54 ± 1

Special Feature

special features

1. Cool in Summer,Warm in Winter: Walton has introduced new heating and cooling model air conditioner for ensuring you're comfortable both in winter and summer. Even if you live in extreme temperature, depending on the weather you can control your room temperature by heating in winter and cooling in summer.

2. LUNGS DOCTOR (IONIZER): Walton Air-Conditioner comes with lonizer (a device that generates negative ion) that filtrates dusts, smoke, bacteria and odor from room air ensuring pure and healthy breath.

3. SILENT OPERATION: WALTON Air-Conditioner's indoor unit creates minimum amount of noise with a feel of natural breeze.

4. AUTOMATIC MULTI DIRECTIONAL AIR-FLOW: WALTON Air-Conditioner has automated vertical and horizontal air swing which enable the air to guide at each and every corner of the room.

5. FASTER AND UNIFORM COOLING: With Larger air inlet/outlet area along with bigger cross-flow fan ensures 40% more air flow than traditional Air-Conditioners. It confirms faster and uniform cooling at every corner of the room.

6. WIDE TEMPERATURE RANGE: The air-conditioner can maintain the temperature of your room in between 16°C to 31°C, while outdoor ambient temperature operating range of 20°C to 46°C.

7. ENERGY EFFICIENT: WALTON Air-Conditioner ensures a higher COP of 2.8 (Cooling) & 3.19 (Heating) that means you will get higher cooling/heating output with minimum power input.

Warranty Information

product replacement warranty

1 Year (Note: if there are manufacturing faults in the heat exchanger & compressor)

residential use

Compressor Guarantee: 5 Years

Spare Parts Support: 3 Years

After Sales Service: 1 Year (Free)

commercial use

Compressor Guarantee: 5 Years

Spare Parts Support: 2 Years

After Sales Service: 1 Year (Free)

Terms & Conditions

Warranty Terms & Conditions

1. This warranty does not cover the following cases -

i) The warranty will be invalid if the product is misused, neglected, or rented on a commercial basis. The warranty also will be invalid if repaired, replaced modified by unauthorized service personnel.

ii) If the product serial number/barcode is removed, altered, or duplicated, the warranty will be invalid.

2. This warranty covers only manufacturing defects in products & workmanship, subject to verification by company personnel.

3. Authority reserves the right to change, extend, correct, stop or cancel the warranty period without any prior notice
