"Key Features

24-bit/192kHz resolution for professional recording and monitoring

Hi-Speed USB circuitry for fastest connection, with class-leading round-trip latency of 2.59ms*

Transparent Crystal™ preamps and ultra-pristine A/D converters for unsurpassed audio recording quality

VU LED meters for dialing in the perfect level

Flexible inputs: (2) XLR+¼” TRS combo or ¼” instrument inputs

Use any combination of TRS combo or ¼” instrument input on the two channels:(2) TRS, (2) instrument or (1) of each

5-pin MIDI input/output for connecting virtually any external MIDI gear

Stereo ¼” outs; ¼” headphone out with independent level control

Rugged metal chassis; large central control for easy volume adjustment

USB/Direct knob for balancing between the input signal and the computer signal

*Round trip latency is dependent on buffer settings, and computer hardware.

Specifications

Minimum System Requirements

macOS: 10.8 Class Compliant

PC: Windows 7, Windows Driver

Standard USB 2.0 or USB-C Port

Mic Inputs 1-2 (balanced XLR)

FREQUENCY RESPONSE 20 Hz – 20 kHz (+0.1 dB)

DYNAMIC RANGE 104 dB (A-weighted)

SIGNAL-TO-NOISE RATIO 104 dB (+1.0 dBu, A-weighted)

THD+N 0.002%

PREAMP EIN -128 dBu (max gain, 150 Ω source, A-weighted)

MAX INPUT LEVEL +1.5 dBu

GAIN RANGE 55 dB

Line Input 1-2 (balanced 1/4″ [6.35 mm] TRS)

FREQUENCY RESPONSE 20 Hz – 20 kHz (+0.05 dB)

SIGNAL-TO-NOISE RATIO 101 dB (1 kHz, +4 dBu, A-weighted)

THD+N 0.002%

MAX INPUT LEVEL 16 dBu

GAIN RANGE 55 dB

Inst Input 1-2 (unbalanced 1/4″ [6.35 mm] TS)

FREQUENCY RESPONSE 20 Hz – 20 kHz (+0.05 dB)

DYNAMIC RANGE 100 dB (A-weighted)

SIGNAL-TO-NOISE RATIO 98 dB (+ 4 dBu, A-weighted)

THD+N 0.005%

MAX INPUT LEVEL 6 dBu

INPUT IMPEDANCE 1 MΩ

GAIN RANGE 24 dB

Main Outputs, L and R (balanced 1/4″ [6.35 mm] TRS)

FREQUENCY RESPONSE 20 Hz – 20 kHz (+0.05 dB)

DYNAMIC RANGE / SIGNAL-TO-NOISE RATIO 106 dB (A-weighted)

THD+N 0.005%

MAX OUTPUT LEVEL +13 dBu (1 kHz, -1 dBFS)

Headphone Output (1/4” [6.35 mm] TRS)

THD+N 0.005%

OUTPUT IMPEDANCE 10 Ω

General

POWER USB-bus-powered

DIMENSIONS (WIDTH X DEPTH X HEIGHT) 8.0” x 6.0” x 2.76” (20.42 cm x 15.24 cm x 7.0 cm)

WEIGHT 2.1 lbs. 0.95 kg

Downloads

AIR 192-6 User Guide v1.1

What’s In the Box

AIR 192|6

USB-C-to-USB-C Cable

USB-C-to-USB-A Cable

Software Download Cards

User Guide

Safety and Warranty Manual"
