"Features

1 Channel UHF PLL diversity wireless receiver with fixed antenna

Information-rich on board LCD display

105dB S/N ratio; < 0.6% @ 1KHz T.H.D

1 x independent balanced XLR & 1 x 6.3mm unbalanced output

Specifications

RU-8011DB

Frequency Preparation PLL Synthesized Control

Carrier Frequency Range 470~960 MHz

Frequency Setting REMOSET U

Receiving Mode Antenna Diversity

Bandwidth 36MHz

S/N Ratio >105dB(A)

T.H.D <0.6%@1KHz

Sensitivity -95dBm,S/N>80dB

Rejection Ratio >80 dB

Frequency Response 50Hz~16KHz±2dB

Antenna Type BNC Socket

Antenna Booster Power DC12~15V/100mA

Display LCD

Display Contents Group, Channel, Frequency, Battery Level, Antenna A/B, Mute Display, AF Meter, RF

Meter, Frequency Scan, Audio Level, Volume

Controls Power ON/OFF, Group, Channel, Frequency, Mute Display, Key Lock, Volume, Output

Attenuaiton(XLR), Frequency Scan(ON/OFF)

Audio Output Level Ref/ ±22.5KHz Dev@1KHz Tone

ψ6.3 Phone Jack/ -10dBV

XLR Jack/ -4dBV(Line) ˴ -24dBV(MIC)

Audio Output Impedance 600Ω

Squelch Pilot Tone & Noise Mute

Output Connector 1 independent balanced XLR and one Ø6.3mm unbalanced.

Power Supply DC12~15V/300mA

Dimension (mm) 212.3mm(W)* 38.3mm(H)* 144mm(D)

Notes Acutal product specifications may vary depending on region

RU-850LTH

Frequency Preparation PLL Synthesized Control

Carrier Frequency Range 470~960MHz

Frequency Setting REMOSET U(Receive)

RF Outpus Low / High

Stability <±10KHz@Fc

Frequency Deviation ±48KHz

Spurious Emissions <-50dBc

Function Mute, Auto Power Off, Sensitivity Adjust, Low Battery

Display LCD+LED

Controls Power, Mute, Group, Channel,

Frequency, Gain Adjust, Auto Power Off, Key

Lock

Battery UM3, AA x2

RU-G3TH (Option)

Frequency Preparation PLL Synthesized Control

Carrier Frequency Range UHF 470~960 MHz

Frequency Setting Remoset U Ultrasonic

RF Outputs Low/High

Stability <±10KHz@ Fc

Frequency Deviation ±48KHz

Spurious Emissions <-50dBc

Display LCD+LED

Controls Power ON/OFF, Mute ON/OFF, Group, Channel, Frequency, GAIN Adjust, Auto Power Off Adjust, Lock-on Mode

Battery UM3, AA x2

Slot-in Charging Yes

Dimensions 50(W) x 253(H) x 35.5(D)

Notes Actual product specifications may vary depending on model and region.

RU-850LTB

Frequency Preparation PLL Synthesized Control

Carrier Frequency Range 470~960MHz

Frequency Setting REMOSET U(Receive)

RF Outpus Low / High

Stability <±10KHz@Fc

Frequency Deviation ±48KHz

Spurious Emissions <-50dBc

Function Mute, Auto Power Off, Sensitivity Adjust, Low Battery

Display LCD+LED

Input Connector 4P Mini XR

Controls Power, Mute, Group, Channel,

Frequency, Gain Adjust, Auto Power Off, Key

Lock

Battery UM3, AA x2"
