"Features

The extension of your screen

A USB-C port is designed on Kamvas 22 Plus for the connection to your tablet, computer, game console, or Android phone. Via a USB-C to USB-C cable, users can enjoy working or gaming on this 21.5inch large screen.

Adjustable stand for better efficiency

The ergonomically designed grey metallic stand not only matches the color of the pen display but also allows users to create at a more comfortable angle from 20°to 80°, which helps to improve the productivity. Additionally, the device is sleek and slim with its thickness ranges from 19mm to 26.7mm.

Strong compatibility

Kamvas 22 Plus can work seamlessly with devices running on Windows, macOS, Linux OS or Android, and supports various mainstream drawing and designing software.

Specifications

Display Features Panel Size: 21.5inch (Diagonal)

Resolution: 1920 X 1080 (16:9)

LCD Type: IPS

Active Area: 476.64 X 268.11mm

Contrast Ratio: Kamvas 22 Plus: 1200:1

Brightness: 220cd/M2 (Max.)

Viewing Angle: 89°/89°(H)/89°/89°(V) (Typ.)(CR＞10)

Gamut: Kamvas 22 Plus: 140% SRGB

Display Color: 16.7M (8bit)

General Pen Technology: Battery-Free Electromagnetic Resonance

Pen Resolution: 5080 LPI

Pressure Levels: 8192 Levels

Accuracy: ±0.3mm (Center), ±2mm (Corner)

Reading Height: 10mm

Report Rate: ＞220PPS

Tilt Recognition: ±60°

Digital Pen: PW517

Input Voltage: AC 100-240V, 50/60Hz

Output Voltage: 12V 3A

Video Interface: USB-C × 2; USB-A × 1

Adjustable Stand: ST100A (Grey)

OS Support: Windows 7 Or Later, MacOS 10.12 Or Later Android（USB3.1 DP1.2）

AG Glass: Kamvas 22 Plus: Etched Anti-Glare Glass

Others Full Lamination: Kamvas 22 Plus: YES

Power Consumption: ≤24W

Standby Consumption: ≤0.3W

Working Temp. And Humidity: 0-40°C, 20-80%

Storage Temp. And Humidity: -20°C~60°C, 10-90%

Dimension: 546 X 323 X 19~26.7 Mm (Without Stand)

Net Weight: 3.9 KG (With Stand)"
