Specifications:

Accessory Port:

• NATO Ports
• 1/4"-20 Mounting Hole
• Cold Shoe
• Video Transmission/Focus Motor Port (USB-C)
• RSS Camera Control Port (USB-C)
• Focus Motor Port (USB-C)

Battery:

• Model: BHX711-3000-7.2V
• Type: 2S
• Capacity: 3000mAh
• Energy: 21Wh
• Runtime: 12 hours [1]
• Charging Time: Approx. 2.5 hours when using 18W quick charging (supports PD protocol)
• Suggested Charging Temperature: 5° to 40° C (41° to 104° F)

Connections:

• Bluetooth 5.0
• Charging Port (USB-C)
• Ronin App Requirements
• iOS 11.0 or above
• Android 7.0 or above
• Languages Supported by the Touchscreen

Working Performance:

• Tested Payload: 3 kg (6.6 lbs)
• Maximum Controlled Rotation Speed (Pan | Tilt | Roll): 360°/s
• Mechanical Range: Pan axis: 360° continuous rotations | Roll axis: -95° to +240° | Tilt axis: -112° to +214°

Mechanical & Electrical Properties:

• Operating Frequency: 2.400-2.4835 GHz
• Bluetooth Transmitter Power: <8 dBm
• Operating Temperature: -20° to 45° C (-4° to 113° F)

Weight:

• Gimbal: Approx. 990 g (2.18 lbs)
• Grip: Approx. 200 g (0.44 lbs)
• Extended Grip/Tripod (Plastic): Approx. 183 g (0.4 lbs)
• Upper and Lower Quick-Release Plates: Approx. 107 g (0.23 lbs)

Dimensions:

• Folded: 254×230×68 mm (L×W×H, excluding camera, grip, and the Extended Grip/Tripod)
• Unfolded: 364×187×170 mm (L×W×H, height includes the grip and excludes the Extended Grip/Tripod)

DJI Ronin Image Transmitter:

• Connections: Power/Communication Port (USB-C)
• HDMI Port (Mini HDMI): RSS Camera Control Port (USB-C)
• Expansion Port: Cold Shoe
• Operating Frequency: 2.400-2.484 GHz | 5.725-5.850 GHz
• Transmitter Power (EIRP): 2.400-2.4835 GHz | <25 dBm (FCC) | <20 dBm (CE/SRRC/MIC) | 5.725-5.850 GHz: | <25 dBm (FCC/SRRC) | <14 dBm (CE)
• Battery: Capacity: 2970 mAh | Compatible Charger: 5V/2A | Charging Time: Approx. 2.5 hours | Max Battery Life: Approx. 3.5 hours
• Transmission Range:200m (SRRC/FCC) [2] | 100m (CE) [2]
• Latency: 60ms
• Operating Current/Voltage: 900 mA, 3.7V
• Operating Temperature: 0° to 45° C (32° to 113° F)
