Specifications:

Accessory Connections:

• 1/4” Mounting Hole
• 3/8” Mounting Hole
• Camera Control Port
• Accessory Port
• USB-C Port
• RSA Port

Intelligent Battery:

• Type: 18650 Li-Po
• Capacity: 2450mAh
• Power: 17.64Wh
• Battery Life: 11 h
• Charging Time: 2.5 h (5 V/2 A)
• Charging Temperature: 5° to 40°C (41° to 104°F)

Connections:

• Bluetooth: 5.0
• Port: USB-C

Mobile Assistant Software Requirements:

• iOS 9 or above
• Android 5.0 or above

Working Performance:

• Tested Payload: ≤ 2.0 kg
• Angular Vibration Range: ±0.02°

Maximum Controlled Rotation Speed:

• Pan axis control: 180°/s
• Tilt axis control: 180°/s
• Roll axis control: 180°/s

Mechanical Endpoint Range:

• Pan axis control: 360° continuous rotation
• Tilt axis control: -202.5° to +112.5°
• Roll axis control: -95° to +220

Controlled Rotation Range:

• Pan axis control: 360° continuous rotation
• Tilt axis control: -90° to 145°
• Roll axis control: ±30°

Mechanical & Electrical Characteristics:

• Working Current: Static current: 0.2 A
• Working Frequency: 2.400 GHz to 2.4835 GHz
• Transmission Power: ≤ 8 dBm
• Operating Temperature: -20° to 45°C (-4° to 113°F)

Gimbal Dimensions:

• Folded: 220×200×75 mm
• Unfolded: 370×165×150 mm
