"Features

Print, Scan, Copy, Fax

ISO Standard print speed (A4): up to 8.8 ipm black / 5.0ipm color

Wireless, Mopria, AirPrint, Direct Wireless

Recommended monthly print volume: 150 – 1500 pages

Integrated Ink Tank System

Built-in integrated ink tanks create a compact printer body. Users can also view remaining ink levels easily at a glance.

Spill-Resistant Ink Bottle Design

The ink bottles come with a special tip design that reduces spillage during ink refilling.

Auto Document Feeder

20-sheet ADF for copying/scanning

Support Borderless Printing

Print borderless photos up to A4 size.

Specifications

Printer

Maximum Printing Resolution 4800 (horizontal) x 1200 (vertical) dpi

Print Head / Ink Number of Nozzles: Total 1,472 nozzles

Ink Bottles GI-790 (Black, Cyan, Magenta, Yellow)

Print Speed

Based on ISO / IEC 24734 Document: Col ESAT / Simplex Approx. 5.0ipm

Document: B / W ESAT / Simplex Approx. 8.8ipm

Document: Col FPOT Ready/Simplex Approx. 17 sec

Document: B / W FPOT Ready/Simplex Approx. 11 sec

Document: Col FPOT Sleep/Simplex Approx. 22 sec

Document: B / W FPOT Sleep/Simplex Approx. 14 sec

Photo (4 x 6″) PP-201 / Borderless Approx. 60 sec

Printable Width Bordered: Up to 203.2 mm (8″)

Borderless: Up to 216 mm (8.5″)

Printable Area Borderless Printing Top / Bottom / Right / Left margin: each 0 mm (Supported Paper Size: A4 / Letter / 4 x 6″ / 5 x 7″ / 8 x 10″ / Square (5 x 5″) / Business Card)

Bordered Printing Top margin: 3 mm,

Bottom margin: 5 mm,

Left / Right margin: each 3.4 mm

(Letter / Legal: Left: 6.4 mm, Right: 6.3 mm)

Recommended Printing Area Top margin: 31.2 mm

Bottom margin: 32.5 mm

Paper Size A4, A5, B5, Letter, Legal, 4 x 6″, 5 x 7″, 8 x 10″, Envelopes (DL, COM10), Square (5 x 5″), Business Card, Custom size (width 55 – 215.9 mm, length 89 – 676 mm)

F4 is possible via custom size settings.

Paper Handling (Rear Tray)

(Maximum Number) Plain Paper A4, A5, B5, Letter = 100, Legal = 10

High Resolution Paper (HR-101N) A4, Letter = 80

Photo Paper Plus Glossy II (PP-201) A4, Letter = 10, 4 x 6″ = 20, 5 x 7″, 8 x 10″ = 10, Square (5 x 5″) = 20

Photo Paper Plus Semi-Gloss (SG-201) A4, Letter = 10, 4 x 6″ = 20, 5 x 7″, 8 x 10″ = 10

Matte Photo Paper (MP-101) A4, Letter = 10, 4 x 6″ = 20

Envelope European DL / US Com. #10 = 10

Glossy Photo Paper “Everyday Use” (GP-508) A4 = 10, 4 x 6″ = 20

Photo Paper Plus Glossy II (PP-208) A4, 4 x 6″ = 10

Photo Sticker PS-108, PS-308R, PS-208, PS-808 = 1

Paper Weight Rear Tray Plain Paper: 64 – 105 g/m2, Canon specialty paper: max paper weight: approx. 275 g/m2 Photo Paper Plus Glossy II (PP-201)

Ink End Sensor Dot count

Print Head Alignment Manual

Scan

Scanner Type Flatbed

Scanning Method CIS (Contact Image Sensor)

Optical Resolution 600 x 1200 dpi

Scanning Bit Depth (Input / Output) Grayscale: 16 / 8-bit

Color: 48 / 24-bit (RGB each 16 / 8-bit)

Line Scanning Speed*6 Grayscale: 1.5ms/line (300 dpi)

Color: 3.5ms/line (300 dpi)

Maximum Document Size Flatbed: A4 / Letter (216 x 297 mm)

ADF: A4 / Letter / Legal

Copy

Maximum Document Size A4 / Letter

(ADF: A4, Letter, Legal)

Compatible Media Size: A4 / A5 / B5 / Letter / Legal / 4 x 6″ / 5 x 7″ / Business Card

Type: Plain Paper

Photo Paper Plus Glossy II (PP-201)

Photo Paper Plus semi-gloss (SG-201)

Glossy Photo Paper “Everyday Use” (GP-508)

Matte Photo Paper (MP-101)

Photo Paper Plus Glossy II (PP-208)

Image Quality 3 positions (Draft, Standard, High)

Density Adjustment 9 positions, Auto intensity (AE copy)

Copy Speed*7

Based on ISO / IEC 24734. Document: Color

sFCOT / Simplex Approx. 24 sec

Document: Color

sESAT / Simplex Approx. 3.5ipm

Document (ADF): Color

ESAT/Simplex Approx. 2.5ipm

Document (ADF): B/W

ESAT/Simplex Approx. 8.0ipm

Multiple Copy Black / Color: Max. 99 pages

Fax

Type Desktop Transceiver (Super G3 / Color Communication)

Applicable Line PSTN (Public Switched Telephone Network)

Transmission Speed Black Approx. 3 sec (33.6 kbps)

Color Approx. 1 min (33.6 kbps)

Fax Resolution Black 8 pels/mm x 3.85 lines/mm (Standard)

8 pels/mm x 7.7 lines/mm (Fine)

300 x 300 dpi (Extra Fine)

Color 200 x 200 dpi

Print Size A4, Letter, Legal

Scanning Width 208 mm (A4), 214 mm (LTR)

Modem Speed Maximum 33.6kbps (Automatic fall back)

Compression Black MH, MR, MMR

Color JPEG

Gradation Black 256 levels

Color 24-bit Full Color (RGB each 8-bit)

ECM (Error Correction Mode) ITU-T T.30 compatible

Automatic Dialing Group Dialing Max. 19 locations

Transmission / Reception Memory Approx. 50 pages

PC Fax

Type Windows: Available, Mac: Available

Destination Number 1 location

Black / Color B / W transmission only

Network

Protocol TCP / IP

Wireless Network Type: IEEE 802.11n / IEEE 802.11g / IEEE 802.11b

Frequency Band: 2.4 GHz

Channel 1 – 13

Range: Indoor 50m (depends on the transmission speed and conditions)

Security: WEP 64 / 128-bit, WPA-PSK (TKIP / AES), WPA2-PSK (TKIP / AES)

Direct Connection (Wireless LAN) Available (AP Mode only)

Printing Solutions

Apple AirPrint Available

Layout 1-up (bordered / borderless) Letter, A4, 4 x 6″, 5 x 7″, 8 x 10″, Square 5 x 5″, Business card

1-up (bordered only) A5, B5, Legal, #10 Envelope, DL Envelope, Custom size

Print Quality Standard / High

Mopria Available

Smart Device Print Plug-In

(for Android / Amazon device) Available

PIXMA Cloud Link From smartphone or tablet: Available

Canon PRINT Inkjet / SELPHY App

(for iOS / for Android)

Canon Easy-PhotoPrint

(for Windows RT) Available

Layout 1-up (bordered / borderless) Letter, A4, 4 x 6″, 5 x 7″, 8 x 10″, Square 5 x 5″, Business card

1-up (bordered only) A5, B5, Legal

Print Quality Fixed

System Requirements Windows: Windows 10, Windows 8.1, Windows 7 SP1

Macintosh: OS X 10.10.5 ~ 10.11, macOS 10.12

Others: Chrome OS

General Specifications

Operation Panel Display Full dot

Language 32 Languages Selectable: Japanese /

English (mm & inch) / German /

French / Italian / Spanish / Dutch /

Portuguese / Norwegian / Swedish /

Danish / Finnish / Russian / Czech /

Hungarian / Polish / Slovene /

Turkish / Greek / Simplified Chinese /

Traditional Chinese / Korean /

Indonesian / Slovakian / Estonian /

Latvian / Lithuanian / Ukrainian /

Romanian / Bulgarian / Croatian /

Vietnamese

ADF Paper Handling (Plain Paper) A4, Letter = 20, Legal = 5

Interface USB 2.0 Hi-Speed

Paper Output Tray A4, Letter = 50, Legal = 10

Operating Environment*13 Temperature: 5 – 35°C

Humidity: 10 – 90% RH (no dew condensation)

Recommended Environment Temperature: 15 – 30°C

Humidity: 10 – 80% RH (no dew condensation)

Storage Environment Temperature: 0 – 40°C

Humidity: 5 – 95% RH (no dew condensation)

Quiet Mode Available

Acoustic Noise (PC Print) Plain Paper (A4, B/W) Approx. 53.5 dB(A)

Power AC 100 – 240 V; 50/60 Hz

Power Consumption Connection to PC USB

OFF: Approx. 0.2 W

Standby (scanning lamp is off):

(USB connection to PC) Approx. 0.9 W

Standby (all ports connected, scanning lamp is off) Approx. 1.6 W

Copying Approx. 10 W

Environment Regulation: RoHS (EU, China), WEEE (EU)

Dimension (W x D x H) Factory configuration Approx. 445 x 330 x 197 mm

Output / ADF trays extended Approx. 445 x 526 x 249 mm

Weight Approx. 7.3 kg"
