"Specification

Printer

Maximum Printing Resolution 4800 (horizontal) x 1200 (vertical) dpi

Print Head / Ink Number of Nozzles: Total 1,472 nozzles

Ink Bottles GI-790 (Black, Cyan, Magenta, Yellow)

Print Speed

Based on ISO / IEC 24734

Click here summary report Document: Col ESAT / Simplex Approx. 5.0 ipm

Document: B / W ESAT / Simplex Approx. 8.8 ipm

Document: Col FPOT Ready/Simplex Approx. 19 sec

Document: B / W FPOT Ready/Simplex Approx. 13 sec

Document: Col FPOT Sleep/Simplex Approx. 21 sec

Document: B / W FPOT Sleep/Simplex Approx. 14 sec

Photo (4 x 6″) PP-201 / Borderless Approx. 60 sec

Printable Width Bordered: Up to 203.2 mm (8 inch)

Borderless: Up to 216 mm (8.5 inch)

Printable Area Borderless Printing Top / Bottom / Right / Left margin: each 0 mm (Supported Paper Size: A4 / Letter / 4 x 6″ / 5 x 7″ / 8 x 10″ / Square (5 x 5″) / Business Card)

Bordered Printing Top margin: 3 mm,

Bottom margin: 5 mm,

Left / Right margin: each 3.4 mm

(Letter / Legal: Left: 6.4 mm, Right: 6.3 mm)

Recommended Printing Area Top margin: 31.2 mm

Bottom margin: 32.5 mm

Paper Size A4, A5, B5, Letter, Legal, 4 x 6″, 5 x 7″, 8x 10″, Envelopes (DL, COM10), Square (5 x 5″), Business Card, Custom size (width 55 – 215.9 mm, length 89 – 676 mm)

Paper Handling (Rear Tray)

(Maximum Number) Plain Paper A4, A5, B5, Letter = 100, Legal = 10

High Resolution Paper (HR-101N) A4, Letter = 80

Photo Paper Plus Glossy II (PP-201) A4, Letter = 10, 4 x 6″ = 20, 5 x 7″, 8 x 10″ = 10, Square (5 x 5″) = 20

Photo Paper Plus Semi-Gloss (SG-201) A4, Letter = 10, 4 x 6″ = 20, 5 x 7″, 8 x 10″ = 10

Matte Photo Paper (MP-101) A4, Letter = 10, 4 x 6″ = 20

Envelope European DL / US Com. #10 = 10

Glossy Photo Paper “Everyday Use” (GP-508) A4 = 10, 4 x 6″ = 20

Photo Paper Plus Glossy II (PP-208) A4, 4 x 6″ = 10

Photo Sticker PS-108, PS-308R, PS-208, PS-808 = 1

Paper Weight Rear Tray Plain Paper: 64 – 105 g/m2, Canon specialty paper: max paper weight: approx. 275 g/m2 Photo Paper Plus Glossy II (PP-201)

Ink End Sensor Dot count

Print Head Alignment Manual

System Requirements

(Please visit www.canon-asia.com to check OS compatibility and to download the latest driver updates) Windows: Windows 10, Windows 8.1, Windows 7 SP1

Macintosh: Mac OS is not supported

General Specifications

Interface USB 2.0 Hi-Speed

Paper Output Tray A4, Letter = 50, Legal = 10

Operating Environment Temperature: 5 – 35°C

Humidity: 10 – 90% RH (no dew condensation)

Recommended Environment Temperature: 15 – 30°C

Humidity: 10 – 80% RH (no dew condensation)

Storage Environment Temperature: 0 – 40°C

Humidity: 5 – 95% RH (no dew condensation)

Quiet Mode Available

Acoustic Noise (PC Print) Plain Paper (A4, B/W) Approx. 54.5 dB(A)

Power

AC 100 – 240 V; 50/60 Hz

Power Consumption Connection to PC USB

OFF: Approx. 0.2 W

Standby (scanning lamp is off):

(USB connection to PC) Approx. 0.6 W

Standby (all ports connected, scanning lamp is off) Approx. 0.6 W

Printing: G1010 Approx. 11 W

Environment Regulation: RoHS (EU, China), WEEE (EU)

Dimension (W x D x H) Factory configuration Approx. 445 x 330 x 135 mm

Output / ADF trays extended Approx. 445 x 529 x 253 mm

Weight Approx. 4.8 kg

 "
