Basic Information

Brand : Walton

Model : WSI-RIVERINE-18CH

Series name : Riverine

Air conditioner type : Intelligent Inverter

Function : Heating & Cooling

Cooling capacity (ton) : 1.5 Ton

Compressor : Rotary (Inverter)

Refrigerant : R-32

Technology : Latest Intelligent INVERTERCcooling capacity (btu/hr) : 18000 BTU/Hr

Cooling capacity (w) : Cooling: 5275 Watts, Heating: 5275 Watts

Rated voltage : 230V~50Hz

rated power

Cooling: 1470 W,

Heating: 1342

rated current (a)

Cooling : 6.44 A,

Heating: 5.87 A

eer

3.58

cop

3.93

Detailed Information

refrigerant amount (kg) 0.830

operating range (ambient temperature)

Cooling : 20˚C to 55˚C, Heating: –7˚C to 24˚C

Indoor fin type : Louvered Fin (Heat Exchanger)

Outdoor fin type : Slit Fin (Heat Exchanger)

Maximum pipe length : 10m

Auto operation : Yes

Dry mode : Yes (Cooling Mode Only)

Fan mode : Yes

Speed setting : Yes (Auto, High, Medium, Low)

Auto restart : Yes

Comfort cooling : Yes

Timer : Yes

Sleep : Yes

Display type : LCD

Operation/control : Via IR (Infrared Ray)

Child lock : Yes

Temperature unit change : Yes

Auto up-down swing : Yes

Auto left-right swing : Yes

indoor dimensions (mm) [l×w×h]

Unit: 947 x 321 x 232, Packing: 1025 x 400 x 300

outdoor dimensions (mm) [l×w×h]:

Unit: 865 x 370 x 685, Packing: 935 x 435 x 750

Net weight : (indoor) (kg)

12.5 ± 0.5

Gross weight (indoor) (kg) : 15 ± 0.5

Net weight (outdoor) (kg) : 38.5 ± 1

Gross weight : (outdoor) (kg) 44 ± 1

indoor heat exchanger tube type

Copper Tube Condenser

Turbo mode : Yes

Special Feature

special features

1. Cool in Summer,Warm in Winter: Walton has introduced new heating and cooling model air conditioner for ensuring you're comfortable both in winter and summer. Even if you live in extreme temperature, depending on the weather you can control your room temperature by heating in winter and cooling in summer.

2. SILENT OPERATION: Walton Intelligent Inverter Air Conditioner has much quieter and smoother operation than non-inverter type due to BLDC motor usage. The non-inverter makes a lot of noise every time to reach a certain temperature with subsequent on/off feature. Walton Intelligent Inverter Air Conditioner does its function smoothly & silently.

3. FAST COOLING: Compressor & Control board are coupled in such a way that Walton Intelligent Inverter Air Conditioner offers fast cooling by just pressing a single button. (Turbo) of remote control.

4. WIDE TEMPERATURE RANGE: The Walton Intelligent Inverter Air Conditioner features a wide indoor set temperature range of 16°C to 31°C, with an outdoor ambient temperature operating range of 20°C to 55°C.

5. ECO FRIENDLY: Walton Intelligent Inverter Air Conditioner uses R32 & R410a gas as refrigerant which is environment friendly. R32 & R410a refrigerant have Zero Ozone Depletion Potential (ODP) & very low Global Warning Potential Ratings (GWP).

6. MULTI DIRECTIONAL AIRFLOW: Walton Intelligent Inverter Air Conditioner has horizontal & vertical swing which enable the air to guide/swing in four direction. You will feel same comfort at every corner of the room.

7. WIDE WORKING VOLTAGE RANGE: Walton Intelligent Inverter Air Conditioner has wide working voltage range starting from 140V to 264V AC 50Hz.

Warranty Information

product replacement warranty

1 Year (Note: if there are manufacturing faults in the heat exchanger & compressor)

residential use

Compressor Guarantee: 12 Years

Spare Parts Support: 3 Years

Inverter PCB Warranty: 3 years

After Sales Service: 1 Year (Free)

commercial use

Compressor Guarantee: 5 Years

Spare Parts Support: 2 Years

After Sales Service: 1 Year (Free)

Terms & Conditions

Warranty Terms & Conditions

1. This warranty does not cover the following cases -

i) The warranty will be invalid if the product is misused, neglected, or rented on a commercial basis. The warranty also will be invalid if repaired, replaced modified by unauthorized service personnel.

ii) If the product serial number/barcode is removed, altered, or duplicated, the warranty will be invalid.

2. This warranty covers only manufacturing defects in products & workmanship, subject to verification by company personnel.

3. Authority reserves the right to change, extend, correct, stop or cancel the warranty period without any prior notice
