Brand: Walton

Model : WSI-KRYSTALINE (ecOzone)-12F

Series Name : Krystaline

Air Conditioner Type : Intelligent Inverter

Function : Cooling

Cooling Capacity (Ton) : 1 Ton

Compressor : Rotary (Inverter)

Refrigerant : R-290

Technology : Latest Intelligent INVERTER

Cooling Capacity (Btu/Hr) :12000 BTU/Hr

Cooling Capacity (W) : 3517 Watts

Rated Voltage : 230V ~ 50Hz

Rated Power :1070 Watts

Rated Current (A) : 4.76 A

Eer : 3.29

Detailed Information

Refrigerant Amount (Kg) : 0.21 Kg

Operating Range (Ambient Temperature) : 20°C to 55°C

Evaporator Fin Type : Louvered Fin

Condenser Type : Microchannel Condenser

Condenser Fin Type : Wave Fin

Maximum Pipe Length : 10m

Turbo Mode (Maximum Cooling) : Yes

Eco Mode : Yes

Dry Mode : Yes

Auto Operation : Yes

Auto Restart : Yes

Fan Mode : Yes

Speed Setting : Yes (Auto, High, Medium, Low)

Comfort Cooling : Yes

Timer : Yes

Sleep : Yes

Display Type : LCD

Operation/Control : Via IR (Infrared Ray)

Child Lock : Yes

Temperature Unit Change : Yes (°C to °F )

Auto Up-Down Swing : Yes

Auto Left-Right Swing : Yes

indoor dimensions (mm) [l×w×h]

Unit: 844 x 296 x 210 Packing: 910 x 365 x 285

outdoor dimensions (mm) [l×w×h]:

Unit: 844 x 310 x 546 Packing: 900 x 372 x 610

Net Weight (Indoor) (Kg) : 10.7 ± 0.5

Gross Weight (Indoor) (Kg) : 12.85 ± 0.5

Net Weight (Outdoor) (Kg) : 25.9 ± 1

Gross Weight (Outdoor) (Kg) : 29.9 ± 1

Special Feature

special features

1. If room's dimension is changed, no need to change/replace the AC, just change the capacity. The user can control the cooling capacity as per requirement. Thus, it saves energy and ensures optimal cooling.

2. Ecozone: Energy-efficient cooling solution prioritizes environmental responsibility to contribute to a cooler world with a reduced carbon footprint, zero ozone depletion potential (ODP) and very low global warming potential ratings. Enjoy enhanced safety with this innovative R290 refrigerant leak detection system which continuously monitors & detects refrigerant leaks, automatically triggers protective measures if levels exceed safety standards and eliminates flammability risks.

3. SILENT OPERATION: Walton Intelligent Inverter Air Conditioner has much quieter and smoother operation. Its indoor unit creates minimum level of noise with a feel of natural cool breeze.

4. FAST COOLING: Walton Inverter Air Conditioner offers faster cooling for the special combination of the compressor and control board. Only press the "Turbo" button and enjoy the feature.

5. WIDE TEMPERATURE RANGE: The Walton Intelligent Inverter Air Conditioner features a wide indoor set temperature range of 16°C to 31°C, with an outdoor ambient temperature operating range of 20°C to 55°C.

6. ENERGY SAVING: Walton Inverter Air Conditioner has a unique feature named Economy. Just pressing a single button (ECO) will allow the unit to save maximum energy compared to typical non-inverter type air conditioner.

7. WIDE WORKING VOLTAGE RANGE: Walton Inverter Air Conditioner has a wide working voltage range starting from 130V to 280V AC at 50Hz.

Warranty Information

product replacement warranty

Guarantee: 1 Year (Note: if there are manufacturing faults in the heat exchanger & compressor)

residential use

Compressor Guarantee: 12 Years

Spare Parts Support: 3 Years

Inverter PCB Warranty: 3 years

After Sales Service: 1 Year (Free)

commercial use

Compressor Guarantee: 5 Years

Spare Parts Support: 2 Years

After Sales Service: 1 Year (Free)

Terms & Conditions

Warranty Terms & Conditions

1. This warranty does not cover the following cases -

i) If the product is misused, neglected, or rented on a commercial basis. The warranty also will be invalid if repaired, replaced or modified by unauthorized service personnel.

ii) If the product serial number/barcode is removed, altered, or duplicated.

iii) Product defects due to incorrect or negligent storing or use of the products.

iv) Failure to start due to voltage conditions, blown fuses or other damage due to inadequacy or interruption of electrical service.

v) Product defects due to exposure to extreme conditions, e.g. thunder, lightning, water ingress, fire, obstacle to deliver indoor & outdoor airflow.

vi) Damage / failure of product due to rat, cockroach and insects attack etc.

vii) If unit installed in hazards environment by chemical fume, corrosive environment like acid solution, sulfur solution, hydrogen per oxide, sodium sulfate salt, hydrogen Sulfide, Chlorides, bleaching powder, ammonia, chlorine. IPA/Thinner etc.

viii) If unit install in kitchen/oily environment and any heat element/source very near to indoor and outdoor.

2. This warranty covers only manufacturing defects, subject to verification by company personnel.

3. After sales service will be applicable only at company authorized service points.

4. Authority reserves the right to change, extend, correct, stop or cancel the warranty period without any prior notice
