Basic Information

Brand: Walton

Model : WSN-RIVERINE-12F

Series Name: Riverine

Air Conditioner Type : Non-Inverter

Function : Cooling

Cooling Capacity (Ton) : 1 Ton

Compressor :Rotary (Fixed Speed)

Refrigerant : R-410a

Technology : Non-Inverter

Cooling Capacity (Btu/Hr) :12000 BTU/Hr

Cooling Capacity (W) : 3517 Watts

Rated Voltage : 230V ~ 50Hz

Rated Power : 1260

Rated Current (A) : 5.6

Eer : 2.8

Detailed Information

Refrigerant Amount (Kg) : 0.7

Operating Range (Ambient Temperature) : 20˚C to 46˚C

Evaporator Fin Type : Louvered Fin

Copper Tube Condenser: condenser fin type

Slit Fin

Maximum Pipe Length :10m

Turbo Mode (Maximum Cooling) : Yes

Eco Mode : No

Dry Mode : Yes

Auto Operation : Yes

Auto Restart : Yes

Fan Mode : Yes

Speed Setting : Yes (Auto, High, Medium, Low)

Comfort Cooling : Yes

Timer : Yes

Sleep : Yes

Display Type : LCD

Operation/Control : Via IR (Infrared Ray)

Child Lock : Yes

Temperature Unit Change : Yes (16​°C to 31°C)

Auto Up-Down Swing : Yes

Auto Left-Right Swing : Yes

indoor dimensions (mm) [l×w×h]

Unit: 844x 296 x 210, Packing: 910 x 365 x 285

outdoor dimensions (mm) [l×w×h]:

Unit: 721 x 320 x 552, Packing: 825 x 365 x 630

Net Weight (Indoor) (Kg) : 11 ± 0.5

Gross Weight (Indoor) (Kg) : 13 ± 0.5

Net Weight (Outdoor) (Kg) : 28 ± 1

Gross Weight (Outdoor) (Kg) : 32 ± 1

Special Feature

special features

1. LUNGS DOCTOR (IONIZER): Walton Air-Conditioner comes with lonizer (a device that generates negative ion) that filtrates dusts, smoke, bacteria and odor from room air ensuring pure and healthy breath.

2. SILENT OPERATION: WALTON Air-Conditioner's indoor unit creates minimum amount of noise with a feel of natural breeze.

3.Autometic MULTI DIRECTIONAL AIR-FLOW: WALTON Air-Conditioner has automated vertical and horizontal air swing which enable the air to guide at each and every corner of the room.

4. FASTER AND UNIFORM COOLING: With Larger air inlet/outlet area along with bigger cross-flow fan ensures 40% more air flow than traditional Air-Conditioners. It confirms faster and uniform cooling at every corner of the room.

5. WIDE TEMPERATURE RANGE: The air-conditioner can maintain the temperature of your room in between 16°C to 31°C, while outdoor ambient temperature operating range of 20°C to 46°C.

6. ENERGY EFFICIENT: WALTON Air Conditioner ensures higher COP which minimize energy consumption and maximize better performance.

Warranty Information

product replacement warranty

1 Year (Note: if there are manufacturing faults in the heat exchanger & compressor)

residential use

Compressor Guarantee: 5 Years

Spare Parts Support: 3 Years

After Sales Service: 1 Year (Free)

commercial use

Compressor Guarantee: 5 Years

Spare Parts Support: 2 Years

After Sales Service: 1 Year (Free)

Terms & Conditions

Warranty Terms & Conditions

1. This warranty does not cover the following cases -

i) The warranty will be invalid if the product is misused, neglected, or rented on a commercial basis. The warranty also will be invalid if repaired, replaced modified by unauthorized service personnel.

ii) If the product serial number/barcode is removed, altered, or duplicated, the warranty will be invalid.

2. This warranty covers only manufacturing defects in products & workmanship, subject to verification by company personnel.

3. Authority reserves the right to change, extend, correct, stop or cancel the warranty period without any prior notice
