Basic Information

Brand : Walton

Model : WSN-KRYSTALINE-12MH

Series name: Krystaline

Air conditioner type : Non-Inverter function

Heating & Cooling

Cooling capacity (ton) :1 Ton

Compressor : Rotary (Fixed Speed)

Refrigerant : R-32T

Echnology : Non-Inverter

Cooling capacity (btu/hr) : 12000 BTU/Hr

Cooling capacity (w) : 3517 Watts

Rated voltage : 230V~50Hz

Rated power : 1210 (Cooling), 1085 (Heating)

Rated current (a) : 5.35 (Cooling), 4.8 (Heating)

Eer : 2.91

Cop : 3.24

Detailed Information

Refrigerant amount (kg) : 0.65

Operating range (ambient temperature) : 20˚C to 46˚C (Cooling), –7˚C to 24˚C (Heating)

Indoor fin type : Louvered Fin

Outdoor fin type : Slit Fin

Indoor heat exchanger tube type : Copper Tube

Outdoor heat exchanger tube type :Copper Tube

Maximum pipe length : 10m

Turbo mode : Yes

Dry mode : Yes (Cooling Mode Only)

Auto operation : Yes

Auto restart :Yes

Fan mode : Yes

Speed setting : Yes (Auto, High, Medium, Low)

Comfort cooling : Yes

Timer : Yes

Sleep : Yes

Display type : LCD

Operation/control

Via IR (Infrared Ray) : child lock : Yes

Temperature unit change : Yes

Auto up-down swing : Yes

Auto left-right swing : Yes

Indoor dimensions (mm) [l×w×h]

Unit - 844 x 296 x 210,

Packing: 910 X 365 X 285

Outdoor dimensions (mm) [l×w×h]:

Unit: 844 x 310 x 546, Packing: 900 x 372 x 610

Net weight (indoor) (kg) :11 ± 0.5

Gross weight (indoor) (kg) : 13 ± 0.5

Net weight (outdoor) (kg) : 28 ± 1

Gross weight (outdoor) (kg): 32 ± 1

Special Feature

special features

1. COOL IN SUMMER WARM IN WINTER: Walton has introduced new heating and cooling model air conditioner for ensuring you're comfortable both in winter and summer. Even if you live in extreme temperature, depending on the weather you can control your room temperature by heating in winter and cooling in summer.

2. LUNGS DOCTOR (IONIZER): Walton Air-Conditioner comes with lonizer (a device that generates negative ion) that filtrates dusts, smoke, bacteria and odor from room air ensuring pure and healthy breath.

3. SILENT OPERATION: WALTON Air-Conditioner's indoor unit creates minimum amount of noise with a feel of natural breeze.

4. ECO FRIENDLY: Walton Air Conditioner uses R32 gas as refrigerant which is environment friendly. R32 refrigerant has Zero Ozone Depletion Potential (ODP) & very low Global Warning Potential Ratings (GWP).

5. AUTOMATIC MULTI-DIRECTIONAL AIRFLOW: Walton Air Conditioner has Horizontal & Vertical swings which enable the air to guide/swing in four directions. You will feel same comfort at every corner of the room.

6. FASTER AND UNIFORM COOLING With larger air inlet/outlet area along with bigger cross-flow fan ensures more airflow than traditional air conditioners. It confirms faster and uniform cooling at every corner of the room.

7. WIDE TEMPERATURE RANGE: The air-conditioner can maintain the temperature of your room in between 16°C to 31°C, while outdoor ambient temperature operating range of 20°C to 46°C.

8. ENERGY EFFICIENT: Walton Air Conditioner ensures a higher COP of 2.89 (Cooling) & 3.30 (Heating) that means you will get higher cooling output with minimum power input.

Warranty Information

product replacement warranty

Guarantee: 1 Year (Note: if there are manufacturing faults in the heat exchanger & compressor)

residential use

Compressor Guarantee: 5 Years

Spare Parts Support: 3 Years

After Sales Service: 1 Year (Free)

commercial use

Compressor Guarantee: 5 Years

Spare Parts Support: 2 Years

After Sales Service: 1 Year (Free)

Terms & Conditions

Warranty Terms & Conditions

1. This warranty does not cover the following cases -

i) If the product is misused, neglected, or rented on a commercial basis. The warranty also will be invalid if repaired, replaced or modified by unauthorized service personnel.

ii) If the product serial number/barcode is removed, altered, or duplicated.

iii) Product defects due to incorrect or negligent storing or use of the products.

iv) Failure to start due to voltage conditions, blown fuses or other damage due to inadequacy or interruption of electrical service.

v) Product defects due to exposure to extreme conditions, e.g. thunder, lightning, water ingress, fire, obstacle to deliver indoor & outdoor airflow.

vi) Damage / failure of product due to rat, cockroach and insects attack etc.

vii) If unit installed in hazards environment by chemical fume, corrosive environment like acid solution, sulfur solution, hydrogen per oxide, sodium sulfate salt, hydrogen Sulfide, Chlorides, bleaching powder, ammonia, chlorine. IPA/Thinner etc.

viii) If unit install in kitchen/oily environment and any heat element/source very near to indoor and outdoor.

2. This warranty covers only manufacturing defects, subject to verification by company personnel.

3. After sales service will be applicable only at company authorized service points.

4. Authority reserves the right to change, extend, correct, stop or cancel the warranty period without any prior notice.
