"Specifications

Print

Printing Method Color Laser Beam Printing

Print Speed

A4 21 / 21 ppm (Mono / Color)

Letter 22 / 22 ppm (Mono / Color)

2-Sided 12 / 12 ppm (Mono / Color)

Print Resolution 600 x 600 dpi

Print Quality with Image Refinement Technology 1,200 × 1,200 dpi (eq.)

Warm up Time (From Power On) 13 sec or less

First Print Out Time (FPOT)

A4 Approx. 10.4 / 10.5 sec (Mono / Color)

Letter Approx 10.3 / 10.3 sec (Mono / Color)

Recovery Time (From Sleep Mode) 6.1 sec or less

Print Language UFR II, PCL 6, Adobe® PostScript® 3™

Auto Duplex Print Standard

Available Paper Size for Auto Duplex Print A4, B5, Letter, Legal, Executive, Foolscap, Indian Legal

Print Margins 5mm – top, bottom, left and right (Envelope: 10mm)

Print Features Poster, Booklet, Watermark, Page Composer, Toner Saver

Supported File Format for USB Direct Print Supported File Format: JPEG, TIFF, PDF

Copy

Copy Speed A4

A4 21 / 21 ppm (Mono / Colour)

Letter 22 / 22 ppm (Mono / Colour)

Copy Resolution 600 x 600dpi

First Copy Out Time (FCOT)

A4 Approx. 11.4 / 13.4 sec (Mono / Colour)

Letter Approx. 11.2 / 13.1 sec (Mono / Colour)

Maximum Number of Copies Up to 999 copies

Reduce/Enlargement 25 – 400% in 1% increments

Copy Features Frame Erase, Collate, 2 on 1, 4 on 1, ID Card Copy, Passport Copy

Scan

Scan Resolution

Optical Platen glass: up to 600 x 600dpi

Feeder: up to 300 x 300dpi

Driver Enhanced Up to 9,600 x 9,600 dpi

Scan Type Colour Contact Image Sensor

Maximum Scan Size

Platen Glass Up to 216.0 x 297mm

Feeder Up to 216.0 x 355.6mm

Scan Speed 1-Sided: 26.1 ipm (mono), 13.3 ipm (colour)

2-Sided: 51.2 ipm (mono), 26.1 ipm (colour)

Colour Depth 24-bit

Pull Scan Yes, USB and Network

Push Scan (Scan To PC) with MF Scan Utility Yes, USB and Network

Scan To USB (via USB Host 2.0) Yes

Scan To Cloud MF Scan Utility

Scan Driver Compatibility TWAIN, WIA

Send

SEND Method SMB, Email, FTP, iFAX Simple

Colour Mode Full Color, Grayscale, Monochrome

Scan Resolution 300 x 600pi

File Format JPEG, TIFF, PDF, Compact PDF, PDF (OCR)

Fax

Modem Speed Up to 33.6 Kbps

Fax Resolution Up to 408 x 392 dpi

Compression Method MH, MR, MMR, JBIG

Memory Capacity Up to 512 pages

Favourite Dials (in address book) 19 dials

Speed Dial (Coded dials) Up to 281 dials

Group dials / Destinations Max. 299 dials / Max. 299 destinations

Duplex Fax (Transmission) Yes

Sequential Broadcast Max. 310 destinations

Receive Mode Fax Only, Manual, Answering, Fax/Tel Auto Switch

Memory Backup Permanent fax memory backup (Backup with flash memory)

Fax Features Fax Forwarding, Dual Access, Remote Reception, PC Fax (Transmission only), DRPD, ECM, Auto Redial, Fax Activity Reports, Fax Activity Result Reports, Fax Activity Management Reports

Transmission Time Approx. 2.6 sec

Paper Handling

Auto Document Feeder (ADF) DADF: 50 sheets (80g/m2)

Available Paper Size for DADF A4, B5, A5, Letter, Legal, Statement

(Min. 128 x 139.7mm to Max. 216.0 x 355.6mm)

Paper Input

(based on 80g/m2)

Standard Cassette 250 sheets

Multi-Purpose Tray 1 sheet

Optional Paper Feeder N/A

Maximum Paper Input Capacity 251 sheets

Paper Output 100 sheets

Paper Sizes

Cassette A4, B5, A5, Letter, Legal, Statement, Executive, Government Letter, Government Legal, Foolscap, Indian Legal

Custom (Min. 76.2 x 127.0mm to Max. 216.0 x 355.6mm)

Multi-Purpose Tray A4, B5, A5, Letter, Legal, Statement, Executive, Government Letter, Government Legal, Foolscap, Indian Legal, Index Card

Envelope: COM10, Monarch, C5, DL

Custom (Min. 76.2 x 127.0mm to Max. 216.0 x 355.6mm)

Optional Paper Feeder N/A

Paper Types Plain, Thick, Coated, Recycled, Colour, Label, Postcard, Envelope

Paper Weight

ADF 50 to 105g/m2

Cassette /

Optional Paper Feeder 60 to 200g/m2

Multi-Purpose Tray 60 to 200g/m2

Connectivity & Software

Standard Interfaces

Wired USB 2.0 High Speed, 10Base-T/100Base-TX/1000Base-T

Wireless Wi-Fi 802.11b/g/n

(Infrastructure mode, WPS easy Setup, Direct Connection)

Near Field Communication (NFC) N/A

Network Protocol

Print LPD, RAW, WSD-Print (IPv4, IPv6)

Scan Email, SMB, WSD-Scan (IPv4, IPv6), FTP

TCP/IP Application Services Bonjour(mDNS), HTTP, HTTPS, POP before SMTP (IPv4, IPv6), DHCP, ARP+PING, Auto IP, WINS (IPv4), DHCPv6 (IPv6)

Management SNMPv1, SNMPv3 (IPv4, IPv6)

Network Security

Wired IP/Mac address filtering, HTTPS, SNMPv3, IEEE802.1x, IPSEC

Wireless WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (AES)

One-Push Wireless Configuration Wi-Fi Protected Setup (WPS)

Other Features Department ID, Secure Print, Application Library

Mobile Solution Canon PRINT Business, Canon Print Service, Google Cloud Print™, Apple® AirPrint®, Mopria® Print Service

Address Book LDAP

Compatible Operating Systems*3 Windows® 10, Windows® 8.1, Windows® 7, Windows Server® 2016, Windows Server® 2012 R2, Windows Server® 2012, Windows Server® 2008 R2, Windows Server® 2008

Mac® OS X 10.9.5 & up*4, Linux*4

Software Included Printer driver, Fax driver, Scanner driver, MF Scan Utility, Toner Status

General

Device Memory 1 GB

LCD Display WVGA Colour LCD 5.0″ Touch Screen Display

Dimensions (W x D x H) 451 x 460 x 413mm

Weight 20.5 kg

Power Consumption

Maximum 850W or less

Average (During Copy) Approx. 370W

Average (During Standby) Approx. 11W

Average (During Sleep) Approx. 0.8W (USB/ LAN / Wi-Fi)

Noise Levels

During Operation Sound Pressure Level: 51dB

Sound Power Level: 69.4dB

During Standby Sound Pressure Level: Inaudible

Sound Power Level: 43dB

Operating Environment

Temperature 10 – 30°C

Humidity 20% – 80% RH (no condensation)

Power Requirements AC 220-240 V (±10%), 50/60 Hz (±2Hz）

Toner Cartridge

Standard Cartridge 054 BK: 1,500 pages (bundled: 1,500 pages)

Cartridge 054 C/M/Y: 1,200 pages (bundled: 680 pages)

High Cartridge 054H BK: 3,100 pages

Cartridge 054H C/M/Y: 2,300 pages

Monthly Duty Cycle 30,000 pages

Optional Accessories

Paper Feeder N/A

Barcode Printing Barcode Printing Kit-E1

Attachment kit for NT-Ware Mi-Card Mi-Card Attachment Kit-B1"
